Loudspeaker
KIDROCK
SFASPKKD0076
Product Description
| Model | WQU-206 | WQU-206S | WQU-206SA | WQU-208 | WQU-208S | WQU-208SA |
| Compose | 6.5"×2+1.7" | 15"×1 | Single 15 inch active line array subwoofer, one active subwoofer for 4 QU206 line array | 8"×2+1.7"Neodymium magnet | 18"×1 | Single 18 inch active line array subwoofer, one active subwoofer for 4*QU208 line array |
| Frequency Response | 85Hz-18KHz（-10dB） 30Hz-300Hz（±3.5dB） | 40Hz-250Hz（-10dB） | 40Hz-250Hz（-10dB） | 75Hz-18KHz（-10dB） | 35Hz-220Hz（-10dB） | 35Hz-220Hz（-10dB） |
| Impedance | 16Ω | 8Ω | 8Ω | 16Ω | 8Ω | 8Ω |
| Coverage Angle | 110°H×10°V | N/A | N/A | 110°H×10° | N/A | N/A |
| Power/Peak power | 200W/800W | 500W/2000W | 500W/2000W | 300W/1200W | 600W/2400W | 600W/2400W |
| Input Sensitivity | 96dB/w/m | 99dB/w/m | 99dB/w/m | 98dB/w/m | 100dB/w/m | 100dB/w/m |
| MAX SPL | 125dB | 126dB | 126dB | 123dB | 128dB | 128dB |
| Dimension(HxWxD) | 207*510*299 | 435×510×537 | 435×510×537 | (260×173)×578×370 | 508×578×610 | 508×578×610 |
Built in | Built in amplifier module Input voltage：0.775V 1500W+1500W/4 Ω | Built in 1800W+1800W/4 Ω high-efficiency dual feedback D-class digital amplifier module |
