Loudspeaker
KIDROCK
SFASPKKD0048
Product Description
| Model | WX-10 | WX-12 | WX-15 | WX-215 |
| Compose | 10"+1.7"Horn | 12"+1.7"Horn | 15"+3″ titanium compression driver | 2×15"+3″ complex-diaphragm compression driver |
| Frequency Response | 60Hz-20KHz（-10dB) 75Hz-19KHz（±3.5dB） | 53Hz-20KHz（-10dB) 65Hz-19KHz（±3.5dB） | 45Hz-20KHz（-10dB) 58Hz-19KHz（±3.5dB） | 45Hz-20KHz（-10dB) 50Hz-19KHz（±3.5dB） |
| Power/Peak Power | 250W/1000W | 400W/1600W | 500W/2000W | 250W/1000W |
| Impedance | 8Ω | 8Ω | 8Ω | 4Ω |
| Coverage Angle | 78°H×42° | 76°H×42° | 76°H×45° | 80°H×50° |
| Sensitivity | 97 | 98 | 99 | F103 |
| MAX SPL | 123 | 124 | 126 | 133 |
| Dimension | 330×290×510 | 370×330×580 | 440×400×700 | 530×480×1180 |
Net Weight(KG) Gross Weight(KG) | 17 19 | 22 24 | 32 34 | 46 50 |
